M101 is a face-on spiral galaxy in Ursa Major, approximately 20.9 million light-years from Earth. Designated NGC 5457 and commonly called the Pinwheel Galaxy, it presents its full disk to the line of sight at an inclination of roughly 18 degrees, which makes the spiral arm structure directly available to the camera. This session documents 6 hours and 18 minutes of total integration on M101 using 60-second sub-exposures at gain 50, a return to a known-good setting after earlier testing at 120 seconds produced data that did not justify the longer exposure time.
What this post covers
In this post you will find the reasoning behind the return to 60-second sub-exposures from 120 seconds, how a growing dark library at the same setting and across multiple ambient temperatures contributes to calibration quality, the capture conditions including a half moon setting late in the session and a 1-degree polar alignment deviation, what is visible in the DWARF 3 field beyond M101 itself, and the standard processing workflow from on-device mega stack through Stellar Studio and Snapseed.
Session data
| Target | Messier 101 (NGC 5457) |
| Type | Face-on spiral galaxy |
| Constellation | Ursa Major |
| Distance | ~20.9 million light-years |
| Apparent magnitude | 7.86 |
| Angular size | ~28.8 x 26.9 arcminutes |
| Location | New England, Bortle 6 |
| Moon phase | Half moon, setting late in session |
| Ambient temperature | 38 to 45°F |
| Tracking mode | Guided EQ mode |
| EQ deviation | 1 degree |
| Sub-exposure | 60 seconds |
| Gain | 50 |
| Filter | Astro |
| Total frames (approx.) | ~378 |
| Session duration | ~7 hours |
| Total integration | 6h 18m |
| On-device processing | DWARF app Mega Stack |
| Post-processing | Stellar Studio: denoise, star correction, auto |
| Finishing | Snapseed |
Why 60 seconds instead of 120 seconds
Earlier work on this site tested 120-second sub-exposures under the same Bortle 6 conditions at gain 50. The resulting data did not produce proportionally more usable signal. At 120 seconds the sky background in a Bortle 6 site reaches a level where additional integration time contributes more sky noise than target signal. The histogram position moves unfavorably for faint extended structure like spiral arms, and the signal-to-noise improvement per additional frame diminishes relative to what 60-second subs deliver at the same gain.
60 seconds at gain 50 keeps the histogram in a position where the sensor is collecting efficiently without the sky background dominating the frame. The dark library at this setting has also grown across multiple sessions and multiple ambient temperatures, which improves calibration accuracy. When the mega stack runs, those dark frames are doing more precise work because the library covers a wider range of thermal conditions at matching exposure and gain parameters.
The result here is consistent with that. The spiral arm structure in M101 is resolved, the background is clean, and the stacking behaved predictably through the entire chain.
The half moon and what it did to the data
The moon was a half phase and set late in the session. For the first portion of the 7-hour run it was present in the sky and elevated the sky background in the same way documented in the M106 project. The Astro filter does not selectively reject scattered moonlight for broadband galaxy targets. The effect is a raised background and a gradient in stretched data.
The second half of the session ran under a darker sky as the moon dropped below the horizon. That progression meant the dataset is not uniform across the full 6h 18m of integration. The frames from the later part of the session carry less background noise per sub. The mega stack combines all of them, and the aggregate signal from the total integration is sufficient. The gradient, where present, was addressed in Snapseed finishing.
Polar alignment and session setup
Polar alignment was performed at twilight during setup. Wildlife was active on the hillside during this process: coyotes, owls, or foxes were audible while the DWARF 3 was running through the alignment routine. The resulting deviation was 1 degree from the celestial pole.
At 1 degree of deviation the guided EQ mode on the DWARF 3 remains within its working tolerance. The 7-hour run produced no visible field rotation in the final stack. Ambient temperature during the session ranged from 38 to 45°F. For the uncooled IMX678 sensor those conditions reduce dark current compared to summer sessions at the same settings, which lowers the thermal noise floor before calibration is applied. The dark library covers this temperature range across multiple prior sessions at the same settings.
Processing
The mega stack output from the DWARF app is a linear image requiring stretching before structure becomes visible. Stellar Studio applies denoise, star correction, and auto stretch in sequence. The result goes into Snapseed for finishing: contrast, saturation, and background adjustment. No deviation from the standard workflow was required for this dataset. The half moon gradient was manageable at this integration depth and did not require any session data to be discarded.
What is in the M101 field
M101’s angular diameter of approximately 28.8 arcminutes fits well within the DWARF 3’s 2.93 by 1.65 degree frame, leaving substantial field area around the primary target. Two additional galaxies are visible in this image beyond M101 itself.
At 6 hours and 18 minutes of integration from Bortle 6 skies, faint companions and background galaxies within the field are within detection range, consistent with what has been documented in the M106 and M81 projects on this site.
What comes next
At 6 hours and 18 minutes this is a solid single-session dataset on M101. The mega stack will absorb additional sessions on the same target directly in the DWARF app without reprocessing from scratch. M101’s face-on orientation means additional integration time will continue to develop spiral arm detail and push the detection threshold on the companion objects visible in the field. The M81 project on this site documents what that accumulation produces over time.
Clear Skies!
FAQ
Is M101 a good target for the DWARF 3?
Yes. M101 is a face-on spiral galaxy with an angular diameter of approximately 28.8 arcminutes, which fits within the DWARF 3’s 2.93 by 1.65 degree field of view without cropping the disk. The face-on inclination makes the spiral arm structure directly available at broadband wavelengths. At 6 hours of integration from Bortle 6 skies the spiral arms are resolved and background galaxies are detectable in the same frame.
Why use 60-second sub-exposures instead of 120 seconds?
At 60 seconds and gain 50 the histogram position remains efficient for the IMX678 sensor under Bortle 6 skies. Testing at 120 seconds showed that sky background noise accumulated faster than signal gain from faint structure. 60 seconds also aligns with a growing dark library at matching settings across multiple temperatures, which improves per-frame calibration quality.
Does a half moon affect broadband galaxy data?
Yes. The Astro filter does not block scattered moonlight at the wavelengths galaxies emit. A half moon raises the sky background and introduces a gradient into the stretched stack. The effect is manageable with sufficient integration time. In this session the moon set during the run, so the second half of the dataset was collected under a darker sky, and the combined stack carried enough signal to work with in Snapseed finishing.
What does a 1-degree polar alignment deviation mean for a 7-hour run?
The guided EQ mode compensates for small polar alignment errors through active corrections. At 1 degree of deviation the system remained within its working range. The 7-hour session produced no visible field rotation in the final stack.
Why does a growing dark library improve results?
Dark frames remove fixed-pattern sensor noise. When the library includes frames captured at multiple ambient temperatures at the same exposure and gain settings, calibration accuracy improves across a wider range of real operating conditions. This session ran at 38 to 45°F, a range the existing dark library at 60s gain 50 already covers from prior sessions.
